Yamaha F40

Name: Yamaha F40
Brand: Yamaha
SKU: f40
Availability: InStock

Our 747-cc 40-hp midrange provides powerful performance in a compact package that’s available in both propeller and jet-pump driven models.

All Yamaha outboards

FourStroke

F40

Power: 40 hp
Configuration: 3 cyl
Displacement: 747cc
Weight: 97 kg (214 lbs) - 101kg (223 lbs)

Authorized Yamaha

dealer

View on Yamaha site

About this engine

Our 747-cc 40-hp midrange provides powerful performance in a compact package that’s available in both propeller and jet-pump driven models. With its single throttle valve, long-track intake manifold and electronic control module, it delivers easy starts, fast acceleration and excellent top-end speed.

Key features

Fuel Economy
Single Overhead Camshaft
Precise Throttle Control
Dependable Starting
CONTROL AND COMFORT
EASY ENGINE FLUSHING
POWER TRIM AND TILT

Full specifications

Weight †: 97 kg (214 lbs) - 101kg (223 lbs)
Full Throttle RPM Range: 5000 ~ 6000 rpm
Fuel Induction System: EFI
Recommended Engine Oil: Yamalube® 4M (See owner's manual)
Engine Type: 3 cyl
Displacement: 747cc
Bore x Stroke: 65 x 75mm (2.56 x 2.95 in.)
Prop Shaft Horsepower: 40hp at 5500rpm
Alternator Output at W.O.T.: 17 Amp
Compression Ratio: 9.4:1
Recommended Fuel: Octane 87
Recommended Fuel Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
C.A.R.B. Rating: 2-Star
Exhaust: Through Propeller
Intake: 6
Ignition: CDI Microcomputer
Spark Plug: DPR6EB-9
Starting System: Electric
Lubrication: Wet Sump
Engine Oil Capacity: 1.7L/1.5L
Recommended Cooling: Thermostatic Control
Ethanol Blend Limit: 10% Maximum
Gear Ratio: 2.00:1
Gear Shift: Forward, Neutral, Reverse
Shaft Length: 20"
Degree of Tilt: 20°
Degree of Trim: -3° through +20°
Mounting Centers: N/A
Steering Angle (maximum): 40° from center, either direction
Warranty: Limited 3-year Pleasure, 3-year Government, 1-Year Commercial
